Torquata Stepped Jaws for 75mm Mini Scroll Chuck for Wood Lathe

Do you have a Torquata Mini Scroll Chuck? Want to hold on like your life depends on it? Then check out this Stepped Jaw Set. Completely compatible with the Torquata 75mm Mini Scroll Chuck, these Stepped Jaws will make your mini chuck hold on like Tarzan’s grip. Along with the Torquata Mini Scroll Chuck, this jaw set is perfect for anyone who wants to turn tiny pieces.

These days, if you want to turn wood, you need a scroll chuck. And if you want to turn a broad range of tiny pieces, then you should consider using a mini scroll chuck. Check out these Stepped Jaws to suit the Torquata 75mm Mini Scroll Chuck.

Stepped Jaws for the Torquata 75mm Mini Scroll Chuck

If you want to hold tiny objects such box lids and small vessels, you need these Mini Stepped Jaws from Torquata. Featuring two steps and ribbing on the exterior of the jaws, these Pin Jaws are designed to grip via expansion to any straight wall.

What’s in the box

• 4 x Stepped Jaw segment plates

Please note – the Torquata Mini Stepped Jaws are not compatible with the TSC-100 or any other brand of scroll chuck.

Stepped jaw capacity

It’s only mini, yet it can do a lot.

Step 1

• Max dimensions – Inside 30mm Outside 46mm
• Min dimensions – Inside 2mm Outside 19mm
• Projects 24mm from the chuck face

Step 2

• Max dimensions – Inside 30mm 66mm Outside
• Min dimensions – Inside 2mm Outside 38mm
• Projects 12mm from the chuck face

Easy fit

These Stepped Jaws fit quickly and easily to your mini chuck. It’s basically a two-minute job to change your existing jaws out and set these jaws in. Go get a hold!

Hardened steel

These Stepped Jaws are made by the same manufacturer as the TSC-100. The jaws are made from hardened steel so guarantee years of continual use.

Lifetime warranty

All Torquata products are backed by a limited lifetime warranty. Turn easy knowing you are covered.

About Torquata

Torquata produce a range of router bits, saw blades, woodturning tools and woodworking accessories specified for the Australian woodworker. Torquata tools economical, versatile and well made. Torquata means affordable quality.
